In-Line Flexo Printer Folder Gluer with Automatic Bundling Machine
Fully computerized corrugated carton box production line
Our HS-A series is a complete solution for corrugated carton box manufacturing. This system includes everything you need - from feeding to printing, slotting, die-cutting, folding, gluing, and bundling. What's really outstanding is that this inline flexo folder gluer is that it is all computer-controlled. This means the operator can easily adjust settings, including how the paper is fed into the flexo printer folder gluer.
This carton box folder gluer is perfect for handling big orders efficiently. It quickly switches from one order to another, saving time. You can set the size of your carton boxes - height, length, and width - all through the computer. The in-line flexo printer folder gluer unit is driven by a servo motor, ensuring precision in printing, cutting, and gluing your boxes. If you're in the business of producing large quantities of carton boxes our corrugated cardboard machinery is an ideal choice. It's reliable, fast, and produces high-quality boxes, making it ideal for those large, demanding orders.
Model | |||||||
Max. design speed (pcs/min) | 350 | 300 | 280 | 250 | 200 | 180 | 100 |
Working speed (pcs/min) (depending on cardboard size and printing) | 0-300 | 0-280 | 0-250 | 0-220 | 0-180 | 0-150 | 0-80 |
Max. feeding size (mm) | 900×2000 | 900×2000 | 1200×2400 | 1200×2800 | 1600×2800 | 1600×3600 | 2200×4500 |
Skip feeding size (mm) | 1000×2000 | 1000×2000 | 1600×2400 | 1600×2800 | 1900×2800 | 1900×2800 | 2500×4500 |
Max. printing size (mm) | 850×1950 | 850×1950 | 1150×2350 | 1150×2750 | 1550×2750 | 1550×2600 | 2100×4500 |
Min. feeding size (mm) | 300×765 | 300×765 | 360×785 | 360×785 | 450×850 | 450×850 | 600×900 |
Min. fold size (mm) | 240×120 | 240×120 | 250×120 | 250×120 | 270×120 | 270×120 | 300×140 |
Standard printing plate thickness (mm) | 7.2 | 7.2 | 7.2 | 7.2 | 7.2 | 7.2 | 7.2 |
Max. die cutting size (mm) | 850×1950 | 850×1950 | 1150×2350 | 1150×2750 | 1550×2750 | 1550×3550 | 2100×4500 |
(Size can be customized according to customer requirements)
- Computerized feeder unit
-
- Lead edge feeder with Taiwanese technology
- Touch screen control for configuration
- Equipped with brushes and dust-collecting fans for dust removal
- Computerized printing unit
-
- Top printing machine, with the option of roller transfer or full vacuum transfer
- Optional ceramic anilox roller
- Optional doctor blade ink scraping system.
- Quick-change plate mounting system
- Computerized setting for paper feed pressure
- Top printing machine, with the option of roller transfer or full vacuum transfer
- Computerized drying unit
-
- Single unit operation
- Roller transfer or vacuum transfer optional
- Cold air blowing or electrically heated hot-air drying
- Computerized setting for feeding pressure
- Computerized slotter unit
-
- The slotting unit controls are available on both the main and slotting unit touch screens
- Linear guide rails for lateral movement with universal cross joints
- Touch screen settings for adjusting pre-creasing, creasing, and slotting pressure
- Box height adjustable through the touch screen.
- Significant displacement capability for the middle knife
- Computerized die cutter unit
-
- Speed difference compensation mechanism
- Imported soft anvil rubber pad
- Computerized setting for feeding pressure
- Servo control folder gluer unit
-
- Bottom folder gluer machine
- Vacuum transfer for cardboard feeding
- Large gluing wheel with reticulation gluing, motorized adjustment for glue wheel position
- Controlled by servo motors
- Touch screen for computerized adjustment of box size
- Auto bundling unit
-
- Bundling machine equipped with a PP (Polypropylene) belt
- Automatic alignment for squaring the cartons
- Option for single-line or double-line bundling
